Vanne électromagnétique en laiton de verrouillage bi-directionnelle pour 6VDC eau-air 12VDC 24VDC

2 Way Latching Brass Solenoid Valve For Water Air 6VDC 12VDC 24VDC

Product Features of Latching Brass Solenoid Valve:

1. Working Medium: Air, Water, etc.
2. Working Pressure Range: 0 to 1.2 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4'', 3/8''
5. Orifice Size: 1.6mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Operation: Direct Acting
8. Latching Coil Voltage Option: 6VDC, 12VDC, 24VDC, Instant power-on time (0.3 to 0.5 sec)

Technical Data of Latching Brass Solenoid Valve:

More Latching Solenoid Valves for you to choose:

Brando Factory Production Video of Solenoid Valves:

BRANDO Factory Production Picture of Solenoid Valves:

Packaging and Shiping of Brando Solenoid Valves:

Internal Box	Carton	Pallet

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
