| Lieu d'origine: | LA CHINE |
| Nom de marque: | Brando |
| Certification: | CE |
| Numéro de modèle: | 4V410-15 |
| Quantité de commande min: | 1 PC |
|---|---|
| Prix: | Négociable |
| Détails d'emballage: | Boîte individuelle, carton, palette |
| Délai de livraison: | 4 à 7 jours ouvrables |
| Conditions de paiement: | T/T, PayPal, Western Union |
| Capacité d'approvisionnement: | 200000 PCs par mois |
| Type: | 5/2 manière, solénoïde simple | Taille gauche: | In=Out=Exhaust=1/2 » |
|---|---|---|---|
| Chaîne de pression: | 0,15 à 0.8MPa (21 à 114Psi) | Max Pressure Resistance: | 1.5Mpa (215Psi) |
| Matériel de corps: | Alliage d'aluminium | Max. Frequency: | 3 cycles/en second lieu |
| Mettre en évidence: | Airtac Type Pneumatic Solenoid Valve,4V410-15 Pneumatic Solenoid Valve,Airtac Type 4V410-15 |
||
Airtac Type 4V410-15 5/2 Way Air Control Pneumatic Solenoid Valve
This 4V410-15 solenoid valve is a 5/2 way pneumatic valve which means it has 5 ports; 2 exhaust ports through which air is regulated as it flows out, 2 power ports that power the system, 1 supply port for the inlet of air pressure, and 2 flow positions. This valve is made with an aluminum alloy and has an aperture of 1/2''.
BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.
Technical Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air (to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal Pilot or External Pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 Way 2 Position
|
5 Way 3 Position
|
|||
|
Operating Pressure
|
0.15~0.8 MPa (21~114 psi)
|
||||
|
Proof
|
1.5 MPa (215 psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum Alloy
|
||||
|
Max. Frequency
|
3cycle/sec
|
||||
Dimension of 4V410-15 Pneumatic Solenoid Valve:
Product video of 4V410-15 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
