| Lieu d'origine: | La Chine |
| Nom de marque: | Brando |
| Certification: | CE |
| Numéro de modèle: | 4V410-15 |
| Quantité de commande min: | 1 PC |
|---|---|
| Prix: | $4 to $10 per pc |
| Détails d'emballage: | Boîte individuelle, carton, palette |
| Délai de livraison: | 4-8 jours |
| Conditions de paiement: | L/C, T/T, Western Union, MoneyGram |
| Capacité d'approvisionnement: | 100000 PCs par mois |
| Nom de produit: | Type vanne électromagnétique d'Airtac pneumatique | Tailles de tuyau: | In=Out=Exhaust=1/2 » |
|---|---|---|---|
| Type de fil: | G, PINTE, TNP, BSP | Type de valve: | Solénoïde simple, 5 position de la manière 2 |
| Matériel de corps: | Alliage d'aluminium | Tensions: | 220V C.A., 110V C.A., 24V C.A., 24V C.C, C.C 12V |
| Surligner: | Vanne électromagnétique d'Airtac,5/2 vanne électromagnétique pneumatique de manière,5 vanne électromagnétique pneumatique de position de la manière 2 |
||
5/2 Way Pneumatic Solenoid Valve Airtac Type 4V410-15 1/2" 220V 24V
This is a 4V410-15 Airtac type pneumatic solenoid valve, 1/2'' inlet and out let size, female thread (G, NPT, PT, BSP) connection, 5 way 2 position, several standard voltage levels are optional (12V DC, 24V DC, 110V AC, 220V AC).
Features:
1. Pilot mode: internal pilot or external pilot.
2. Sliding column structure: good sealing and sensitive response.
3. The three-position solenoid valve has three central functions for you to choose from.
4. The dual-control solenoid valve has a memory function.
5. The inner hole adopts special processing technology, which has low friction and wear, low starting pressure and long service life.
6. It can form an integrated valve group with the base to save installation space.
7. Equipped with attached manual equipment to facilitate installation and commissioning.
Product video of 4V410-15 Pneumatic Solenoid Valve:
Main dimension of 4V410-15 Pneumatic Solenoid Valve:
Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal pilot or external pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
|||
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
||||
|
Proof
|
1.5MPa (215psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum alloy
|
||||
|
Max. frequency
|
3cycle/sec
|
||||
Brando Factory Production of Pneumatic Solenoid Valves:
More Pneumatic Solenoid Valves for you to choose:
Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).
Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10
2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15
3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
*4V100 Pneumatic Valves *4V200 Pneumatic Valves *4V300 Pneumatic Valves *4V400 Pneumatic Valves
*5/2 Way Pneumatic Valve *5/3 Way Pneumatic Valve *2/2 Way Pneumatic Valve *Pneumatic Fast Fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
